ASTM B521 Ta1 Pipe Pure Tantalum Tube
-
Quality First
-
Competitive Price
-
First-class Production Line
-
Factory Origin
-
Customized Services
Anhui Fitech Material Co.,Ltd specializes in Tantalum Materials more than 10 years, with rich experience, high quality, and competitive price. As a professional manufacturer and supplier, we have our own professional technology team to meet any of your requirements in quality and technology. If you want to buy Non-ferrous, Metallurgy, Chemical Raw Materials or look for price quotation, or look for price quotation, please contact info@fitechem.com.
Specification (% )
Product Description
High Temperature Alloy Tantalum Capillary Tube 99.95%
Ta&Ta-alloy (such as Ta-2.5W, Ta-10W, Ta-40Nb etc) tube can be used for high-temperature, chemical and atomic industry due to its high melting point, anti-corrosion, good cold workability and other characteristics.It is mainly used to produce reaction container during chemical process , heat exchanger, pipeline, condensing apparatus, bayonet heater, spiral wire, U-tube, thermocouple plus protecting tube and liquid metal container and tube,ect.
Tantalum tube is largely applied to produce tantalum response vessel, tantalum heat exchangers(shell & tube heat exchanger), tantalum pipe line(piping or channel), tantalum condenser, tantalum agitator, tantalum cooler, tantalum boiler, tantalum bayonet heater, tantalum spiral (helical) coil, U-tube heat exchanger or "U" tube bundle heat exchanger during the substance sector for condensing, re-boiling, preheating and cooling of nitric acid, sulfuric acid, hydrochloric acid, formic acid and combinations of those acids with a great deal of other chemicals.
Tantalum tube can be applied in fluid material tanks along with other glass-lined containers, tantalum thermo few and tantalum thermocouple safeguard sheaths, tantalum thermo well, tantalum emitter, tantalum sleeve, tantalum plasma spray focus on and tantalum tubular sputtering target.
| Product Name | Tantalum Tube |
| Material Composition | RO5200,Ta1, RO5252(Ta-2.5W),RO5255(Ta-10W) |
| Purity | ≥99.95% |
| Specifications | O.D: 0.20~100mm Wall thickness: 0.05~10mm |
| The tolerance we could meet: | |
| Out diameter: ±0.003mm Wall thickness: ±0.005mm |
| Chemical composition, Max | ||||||||||||
| Grade | Main components | Impurities Composition, Max | ||||||||||
| Ta | Nb | Fe | Si | Ni | W | Mo | Ti | O | C | H | N | |
| Ta1 (R05200) | reminder | 0.1 | 0.01 | 0.005 | 0.01 | 0.05 | 0.02 | 0.01 | 0.015 | 0.01 | 0.0015 | 0.01 |
| Ta2(R05400) | reminder | 0.1 | 0.01 | 0.005 | 0.01 | 0.05 | 0.02 | 0.01 | 0.03 | 0.01 | 0.0015 | 0.01 |
| Ta2.5W(R05252) | reminder | 0.5 | 0.1 | 0.005 | 0.01 | 2-3.5 | 0.02 | 0.01 | 0.015 | 0.01 | 0.0015 | 0.01 |
| Ta10W(R05255) | reminder | 0.1 | 0.01 | 0.005 | 0.01 | 9-10 | 0.02 | 0.01 | 0.015 | 0.01 | 0.0015 | 0.01 |
| TaNb35(R05240) | reminder | 35.0-42.0 | 0.01 | 0.005 | 0.01 | 0.05 | 0.02 | 0.01 | 0.02 | 0.01 | 0.0015 | 0.01 |
| TaNb3 | reminder | <3.5 | 0.03 | 0.03 | 0.005 | 0.04 | 0.03 | 0.005 | 0.02 | 0.01 | 0.0015 | 0.01 |
| TaNb20 | reminder | 17.0~23.0 | 0.03 | 0.03 | 0.005 | 0.04 | 0.03 | 0.005 | 0.02 | 0.01 | 0.0015 | 0.01 |
| Special requirements to be agreed upon seller and buyer | ||||||||||||
Applications
Application:
Metallurgy, Industrial, Electronic, Medical,etc
Our Tantalum Sheet / Plate products
Our main Tantalum Plate products include pure Tantalum Plate, Ta-10W Sheet, Ta-2.5W Sheet, Tantalum Niobium alloy sheet, etc.
All Western Alloys' Tantalum Sheet / Plate products comply with ASTM standards, such as ASTM B708, ASTM F560, etc.
Tantalum Sheet / Plate applications
Tantalum Sheet and Tantalum Plate can be used in metallurgical industry to make heating parts, heat insulation parts and charging apparatus of vacuum high temperature furnace.
Such as the heating part of heater, bracket, heat insulation screen, crucible, etc.
Tantalum Sheet and Tantalum Plate can also be used in chemical, medical and aerospace industries.
Exhibition Show
Packing & Transportation
FAQs
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
